SPECIFICATIONS
MOTOR: Shimano EP801 Steps Motor
BATTERY: BT-EN806, FOR STEPS, 630Wh Battery lock with 2 keys
DISPLAY: Shimano SC-EM800
FRAME: Tazer Optimized Alloy 29” Front and 27.5″+ Rear Triangle, Enduro link Pivot System, Down tube Flak Guard Armor, Internal Derailleur, Brake, Dropper Post, and Display Unit Routing, ISCG 05 Mount, 150mm travel
FORK: Öhlins RXF 38 M2 Fork, Single Crown, 170mm travel, air spring system
REAR SHOCK: Öhlins TTX22M coil, 155mm travel (Spring 548lbs SM/MD, 640lbs LG/XL)
HEADSET: INTENSE ZS49-ZS56/40
SHIFTERS: TRP EVO 12-speed
REAR DERAILLEUR: TRP EVO 12-speed
CRANKSET: Shimano FC-M8150, 34 tooth chainring, 165mm length
PEDALS: Wellgo platform – B223BN
CHAIN: KMC E 12-speed
CASSETTE: Shimano Deore CS-6100, 12-speed, 10-51t
BRAKES: TRP DH-R EVO, HD-M846
FRONT WHEELSET: 29″ e*thirteen e*Spec 20mm Inner width, 110x15mm including valve & rim tape
REAR WHEELSET: 27.5” e*thirteen e*Spec 35mm Inner width, 148x12mm rear, 6 bolt, including valve & rim tape
FRONT TIRE: Pirelli Scorpion E-MTB S 29″x2.60″ Hyperwall
REAR TIRE: Pirelli Scorpion E-MTB S 27.5″x2.80″ Hyperwall
HANDLEBAR: Renthal Fatbar 35mm diameter 800mm width 30mm Rise
STEM: INTENSE 35mm OD x 45mm Length
GRIPS: ODI Elite Flow
SEATPOST: INTENSE Recon Dropper (SM/MD 125mm, LG/XL 150mm)
SADDLE: SDG Bel-Air V3
WEIGHT: 57.6lbs / 26.025kg (SM/MD,) 58.2lbs / 26.365 (LG/XL), no pedals ; tubeless
