Specifications
Top Speed: 105km/hr
Max Range: 200km
Rated Power: 2000w x2
Max Power: 13440w
Controller: (sine wave) 72V100A 2-in-1 FOC controller
Display Type: TFT display +Kaabo accelerator (IPX7)
Drive Mode: Single/dual motor (switchable)
Battery Nominal Capacity: 2845 Wh
Battery Capacity: Samsung INR21700-50GB
Charger: 84V 1.75A
Charging Time: Approx. 10 hrs（use 2x 2Ah Charger )
Brakes: Front and rear hydraulic brake（160mm） +EABS + Four piston brake blocks
Tires: 100/55-7 Self-healing CST Tires
Suspension System: Adjustable two-arm motorcycle shock absorber（Front)Adjustable 18 level spring damping oil pressure shock absorber(Rear)
IP Rating: IPX5
Open Size: 1365 x 748 x 1348mm
Folding Size: 665 x 748 x 460mm
Net Weight: 148 lbs
Gross Weight: 169 lbs
Removable Motor
The Wolf King GTR Max comes with a removable motor featuring an upgraded 7″ diameter, delivering stronger power and higher efficiency. This upgrade boosts overall performance and durability while simplifying maintenance.
Upgraded Front and Rear Shock Absorption
Master Your Ride
The front shock absorber is upgraded to an adjustable dual arm motorcycle grade shock absorber, and the height is increased from 10mm to 12mm, which makes riding more comfortable; the rear shock absorber is upgraded to a spring damping adjustable oil pressure shock absorber. riders can make personalized adjustments according to riding habits and different scenarios.
High-Performance Lithium Battery Pack
The Wolf King GTR Max is equipped with a high-performance lithium battery pack featuring an aluminum casing and internal sealing for improved waterproofing and stability. The included carrying handle makes it easy to remove and maintain the battery.
- Overcharge Protection
- Over Discharge Protection
- Short Circuit Protection
- Overcurrent Protection
- Low Temperature Protection
- High Temperature Protection
Optimized Foot Deck for Ultimate Comfort
The Wolf King GTR Max features an optimized larger foot deck, offering more space for improved comfort and stability, ensuring every ride is smoother and safer.
2-in-1 FOC Controller
Seamless Control, Boundless Thrills
- Wolf King GTR Max boasts the game-changing 2-in-1 FOC controller developed and tuned entirely by Kaabo. Relying on the layout of the double-layer design and the blessing of smart chips, more accurate algorithms, better collaboration, lightning-fast response time and efficient heat dissipation can be achieved, laying the foundation for an unparalleled journey.
Explore 5 new modes to the fullest
- Sport
mode
- ESP
Mode
- Pedestrian
Mode
- Anti-theft
Mode
- Gears Memory
Mode
Vacuum All-terrain Tires
Upgrade your entertainment to next level
The tires of Wolf King GTR Max are developed in cooperation with CST. They are upgraded to 100-55-7 vacuum all-terrain tires. They have wider treads and stronger grip, suitable for more roads. At extreme speeds over long distances, can also maintain a stable ride.
- Pedal: The height of the pedal above the ground has been reduced from 258mm to 224mm, lowering the center of gravity for improved stability and better handling.
- Kick stand: Upgraded kick stand, smoother and safer.
