SPECIFICATIONS
Model: KS-S18
Top Speed: Full speed unlocked after 10km. Max speed of 50km/h (Factory alarm settings: Level 1- 18km sound alarm Level 2- 19km sound alarm Level 3- Sound alarm with tiltback)
Range: 1110Wh (around 100km)
Maximum Gradibility: approx. 40°
Battery: Rated Power: DC 74V
Top Charging Voltage: DC 84V
Rated Capacity:1110Wh
BMS functions:with balance and protect overshoot/ over discharge/ overcurrent/ short circuit/ overheating function
Operating Temperature: -10C to +60C
Max Load: 120kg
Charger Voltage: Input AC 80~240 V, output DC 84V 2.5A
Charging Time: 1110Wh: about 6h 2.5A
Rated Power: 2200w
Max Power: 5000w
Color: White & black
DIMENSION & WEIGHT
Dimension: 557mm x 530mm x200mm
Suspension Specification: 200-57 Air suspension
Suspension Distance: Using a variable lever the wheel has dampening travel distance of 100mm which is transferred to the rear spring suspension with a travel distance of 57mm.
Pedal Altitude (from ground): 210-110mm
Tire Size: 18inch Diameter 3.0″inch
Weight: 1110wh approx. 22kg
EUC Port: Charging port; Switch port; Light sensor port; USB discharge port
Light UP Displays: Rear light housing displays battery level, braking and turning signals all in one unit
PROTECTIVE MEASURES
Lift Sensor: Lift sensor accurately senses and determines when wheel is lifted off the ground to stop tire rotation.
Roll Protection: 45° left and right side. ( Motor stalls when over 45° )
Place the machine vertically on the ground will restart automatically, no need to restart manually
Speed Limit Protection: Beep alarm or voice alarm when exceed limit speed
Low Battery Protection: Low battery protection activated on 30% battery, speed will decreases linearly; when the battery is lower than 5%, voice alarm for charge, when battery at 0%, the front part of the pedal will rise to decelerate until full stop
Higher Temperature Protection: When the motherboard reaches 80C it will result in tiltback. When the motor reaches 120C it will result in tiltback.
ALARM & FEATURES
Swith On/Off: Short press power key: turn on
Long press: hear a click then turn off
Battery Indicate: 45° left and right siLed shows battery level when EUC power on at rest
HARDWARE FEATURES
Mainboard: The motherboard is designed with a 4 layer structure, allowing for better stability performance. 12 large individual TO-247 imported MOS to sufficiently support the 2200W motor. MOS is attached to the aluminate body frame of the wheel for better heat dissipation.
Bluetooth: Bluetooth 4.0. Allowing strong stable data transmission
USB Output: Quick charge 3.0
Front Light: 2*5w light high beam with 2*4w short beam. Double the strength of the 16x, providing excellent illumination at night
Temperature System: Temperature of the motherboard is continously closely monitorered to ensure rider safety
Handle: Aluminum constructed handle designed for ergonomic pushing of the wheel or lifting of the wheel
Motor: Higher power 2200w motor that provides a maximum torque of 140N.m providing fast acceleration
Suspension System: Unique X shaped suspension system. Racing level suspension provides the ultimate support and shock absorption
ON THE STREET
