MAGNUM NOMAD ELECTRIC FATBIKE
Model: Magnum Nomad
Body Position: Upright
Rider Recommendations: This is a large frame with large wheels/tires. Suggested for riders 5’6″ and taller.
Electric Bike Class: Throttle On-demand (Class 2), Speed Pedelec (Class 3) *Throttle can be removed for Class 1
Warranty: 1 Year Comprehensive
Max Load: 260 lbs
ELECTRONIC DETAILS
Motor Type: Bafang Rear Hub
Motor Output: 48v 750W Nominal
Battery Voltage / Amp Hours / Watt Hours: 48v / 17.5Ah / 840Wh
Estimated Charge Time: 8.5 Hrs
Estimated Min And Max Range: 56-104 Km (Depending On Riding Style, Terrain, Rider Weight and Pedal Assist Level.)
Display Type: LCD Display
Display Readouts: Speed, Trip, Trip Time, Time, ODO, Power output, PAS, Battery Level
Drive Modes: Cadence Sensing Pedal Assist, Twist Throttle
Top Speed: Up to 45 km/hr With Pedal Assist, 32 km/hr Throttle Only
Lights: Front and Rear Integrated
BICYCLE DETAILS
Total Weight: 74lbs
Battery Weight: 9lbs
Frame Type: Low Step with semi-integrated battery
Frame Material: Aluminum
Fork Details: Suspension Fork with Lockout
Gearing Details: 7 Speed Shimano
Shifter Details: Shifter Details:
Cranks: 52T 170mm
Pedals: Welgo Platform
Stem / Handlebar: Promax Adjustable
Brake Details: Hydraulic Disc Brakes
Grips: Leather Ergo
Saddle: Comfort
Seatpost / Seatpost Dimensions: Promax 30.4mm
Fenders: Front and Rear
Rims: 26 x 80mm 36h
Tires: 26″ x 4″
Wheel Size: 26″ X 4″
