ELECTRONIC DETAILS
Motor Type: Das-kit R4 Rear Geared Hub Motor
Motor Output: 48v 500w
Battery Voltage / Amp Hours / Watt Hours: 48v / 12ah / 624wh
Battery Chemistry: Lithium Nickel Cobalt Manganese (Li-ncm)
Estimated Charge Time: 6.5 Hrs
Estimated Min And Max Range: 50 To 80 KM (Depending On Riding Style, Terrain, Rider Weight and Peddle Assist Level.)
Display Type: Fixed, Backlit, Monochrome Lcd
Display Records: Power Output Indicator (6 Bars), Battery Level (6 Bars), Speed, Assist Level (0-6), Odometer, Trip Distance, Trip Time, Battery Voltage
Drive Modes: Cadence Sensing Pedal Assist, Trigger Throttle, Walk Mode
Top Speed: 40 km With Pedal Assist, 32 km Throttle Only
BICYCLE DETAILS
Frame Type: High Step with fully integrated battery
Frame Material: Aluminum Alloy
Fork Details: Sr Suntour XCT ATB Spring Suspension, 100mm, 80mm
Gearing Details: 8 Speed
Shifter Details: Shimano Shifter
Cranks: Shimano
Stem: Promax, Aluminum Alloy
Brake Details: Tektro Hydraulic Disc Brakes
Grips: Velo Flat Rubber
Saddle: Promax
Seatpost / Seatpost Dimensions: Promax
Rims: Aluminum Alloy
Tires: CST Semi-Slick
Wheel Size: 26″
