Engineered for More Than the Ride
The R1+ isn’t an upgrade — it’s an all-new platform. Designed from the ground up with zero compromises, every component was reimagined to deliver unmatched performance. From the frame to the controller, battery, and motor — nothing is borrowed. This is precision engineering with one goal: lead the next era of electric moto. Built by Rerode. Exclusively backed by Pinned Electric.
Form Meets Function
Every detail of the R1+ was sculpted with intent. From its clean lines to the minimalist bodywork, this machine captures the essence of modern design—bold, refined, and unmistakably electric. Engineered to look fast standing still, the R1+ is where performance meets aesthetic precision.
Precision You Can Feel
From the CNC-machined components to the flawless welds, every element of the R1+ reflects Rerode’s commitment to excellence. Built with premium-grade materials and an obsessive eye for detail, this isn’t just a bike—it’s a statement of quality, engineered to perform and built to endure.
SPECIFICATIONS
Frame & Dimensions
• Frame Material: Aluminum alloy
• Overall Size: ~1890 mm × 775 mm × 1100 mm
• Ground Clearance: 268 mm
• Wheelbase: 1280 mm
• Seat Height: 845 mm
• Approx. Weight (with battery): ~65 kg (~143 lb)
• Max Load Capacity: 100 kg (~220 lb)
Power & Performance
• Motor Type: Advanced LPMSM (FOC Sine Wave controller)
• Peak Power: 17 kW (≈23 HP)
• Peak Torque: 500 N·m
• Top Speed: ~95 km/h (~59 mph)
• Max Range: Up to ~120 km (~75 miles) @ 25 km/h (~15 mph)
• Battery: 72 V 40 Ah lithium-ion pack (Samsung 50S 21700 cells)
• Charging Time: ~4 hours (20%–80%)
• Riding Modes: Eco / Sport / Sport+
• Regen Braking: Included
• Controller: FOC Sine Wave Controller
Suspension & Wheels
• Front Suspension Travel: 200 mm
• Rear Suspension Travel: 85 mm
• Front Tire: CST 70/100‑19
• Rear Tire: CST 90/90‑18
• Wheel Type: Straight‑pull spoked wheels
Brakes & Safety
• Front Brake: 220 mm hydraulic disc (DOT fluid)
• Rear Brake: 220 mm hydraulic disc (DOT fluid)
• Brake Thickness: ~3 mm
Display & Electronics
• Display: 2″ TFT screen with app connectivity
• Riding Modes: Eco / Sport / Sport+
• Accessories: USB‑5 V / USB‑C (2400 mA) charging port
• Waterproof Rating: IP65
