ABOUT THIS ITEM
This fork is designed and built for the Talaria Sting MX5 specifications.
Weight for 203mm travel fork: (compatible with 19’ inches/ 70/100-21’Front Tire)
- 45lbs spring – ≤85kg
- 60lbs spring – 85kg-130kg (for lots of jump)
- 45-60lbs progressive spring – 80kg-130kg
Weight for 228mm travel fork: (compatible with 19’/21’ inches)
- 45lbs spring – ≤85kg
- 55lbs spring – 85kg-120kg
FEATURES:
- Center Distance: 750-800mm
- Main Piston Travel: 203-228mm
- Tube Diameter: ∅37mm
- Caliper Mount Spacing: 95.5mm
- Disc Brake Size: ∅220mm (Upgradeable)
- Suitable For: Electric Dirt Bikes, Downhill Bikes
- Damping System: Inverted Oil-Spring
- Adjustments: Multi-stage High-Speed Compression, Low-Speed Compression, Rebound, Spring Preload
- Material: AL6061-T6 Forged Aluminum Alloy Bottom Brackets, AL7075-T6 Aluminum Fork Tubes
- Spring Wire: 55CRSI
- MAX Triple Clamp: CNC Precision Machined
*The upper bearing is excluded. To accommodate various bike models, the fork is supplied without a pre-pressed lower bearing.*
