SPECIFICATIONS
Liquid-cooled, brushless electric motor
22.5 kW peak power, 520 Nm peak torque
Max. range: 120 km (75 miles) on a full charge @ 50 km/h (31 mph)
3 riding modes, traction control, regenerative braking
Turbo mode & reverse gear
Adjustable off-road suspension, 21/18” wheels (front/rear)
Quiet & emissions-free
Switchable headlight & number plate included (North American version only)
Specifications subject to change without notice. Battery ranges are estimated. Actual range may vary
POWERTRAIN
Type
Liquid-cooled, brushless electric (BLDC) motor
Rated Voltage
104V (DC)
Rated Power/Peak Power
10,000W/22,500W
Controller Type
FOC Sine Wave
Peak Torque
520 Nm (383 ft-lbs)
Top Speed
110 km/h (68 mph)
Max Range
120 km @ 50 km/h (75 miles @ 31 mph), depending upon terrain)
Battery
104V/55Ah Lithium Ion
Charger
10A
Charging Time
4 Hours (0-100%)
Drive
530 O-ring Chain
RIDER AIDS
Riding Modes
Sport, Rain, Eco, Turbo
Rider Aids
ASR (Acceleration Slip Reduction, a.k.a. traction control), BERS (Brake Energy Regenerative System)
Reverse Gear
Button-activated
CHASSIS
Front Suspension
47 mm inverted fork, 290 mm travel, adjustable compression & rebound
Rear Suspension
Fully adjustable monoshock, 290 mm wheel travel
Front Wheel
21″ wire-spoked rim, 80/100-21 off-road tire
Rear Wheel
18″ wire-spoked rim, 100/90-18 off-road tire
Curb Weight
127 kg (280 lbs)
Max Load
100 kg (220 lbs)
Vehicle Dimensions
2,080 mm x 805 mm x 1,240 mm (81.9 x 31.7 x 48.8”)
Minimum Ground Clearance
310 mm (12.2″)
Wheelbase
1,430 mm (56.3″)
Seat Height
940 mm (37″)
ADDITIONAL FEATURES
USB Connection
Single USB-2.1A Outlet
Instrumentation
LCD Digital Dash
Headlight
LED
